Details

Performance name of the unit value
Heating Capacity (KW) 38.1
Hot water output of the L / H 885
Heating system input power (KW) 8.8
Noise
dB (A) 69
Use the power 3-/380V ± 10% 50HZ (three-phase four-wire)
Ambient temperature ℃ -5-40
Circulating water ㎡ / h 6.6
Take over the diameter of DN 40
Dimensions Length (MM) 1850
Width (MM) 850
(MM) 1550
Weight KG 510 environmental conditions of dry bulb temperature of 20 ° C, the relativehumidity of 70% cold water 18 ° C of the working conditions. Hot water 55 ° C
